DriveCam specifications
| Event Recorder Unit | |
|---|---|
| WEIGHT | 0.81 lb (370g) |
| DIMENSIONS (W X H X D) | 5.0 x 4.2 x 2.2 in 127 x 107 x 56 mm |
| OPERATING TEMPERATURE | -40°F to 185°F |
| MICROPHONE | Omnidirectional |
| SPEAKER | Yes |
| IN-VEHICLE AUDIBLE ALERTS ON SELECT TRIGGERS | Yes |
| STATUS LIGHTS | 7 LED (wide spectrum) |
| NIGHT VISION ILLUMINATION | 4 high-lumen infrared LED lights |
| MANUAL RECORD BUTTONS | Yes |
| INDUSTRIAL-GRADE HARDWARE | Yes |
| LIMITED WARRANTY | 2 Years |
| Machine Vision + Artificial Intelligence (Configurable) | |
|---|---|
| CONFIGURABLE TRIGGERS AVAILABLE WITH DRIVER SAFETY SUITE AT NO ADDITIONAL CHARGE | Inside View • Handheld Device • No Seatbelt • Driver Smoking • Food or Drink • Inattentive Road View (Enabled by Default) • Rolling Stop • Lane Departure • Following Distance • Critical Distance Speeding Alert |
| Internal | |
|---|---|
| PROCESSOR | iMX8 Quad core + GPU & NPU |
| FIXED MEMORY (EMMC) | 2 GB DDR and 8GB eMMC |
| STORAGE | Up to 400 hours of video |
| MOTION SENSORS | - 9-axis (Accelerometer + Gyro + Magnetometer) - Built-in motion sensor - Built-in GPS multi-constellation GNSS receiver |
| Camera specs | ||
|---|---|---|
| WIDE ANGLE LENS / FIELD OF VIEW | 144° interior HFOV; 96° exterior HFOV | |
| VIDEO RECORDING RESOLUTION | 1920 x 1080** Lytx MV+AI technology uses high resolution cameras during event capture processing to maximize performance. Actual video resolution as viewed in Lytx account may vary. | |
| FRAME RATE | 20 fps** | |
| Yes | |
| Connectivity | |
|---|---|
| CELLULAR | 4G (3G Fallback where supported). Note: 3G may not be supported by all wireless providers. Countries/regions supported: North America, Republic of South Africa, Australia, New Zealand and Europe. |
| WI-FI VIA HOTSPOT | Dual-band Wi-Fi b/g/n/ac |
| BLUETOOTH CAPABLE | Yes |
| ETHERNET | Yes |
| Power | |
|---|---|
| BATTERY | Rechargeable |
| STANDARD INPUT VOLTAGE | 12 V or 24 V |
| CURRENT DRAW IN NORMAL OPERATING MODE | 418 mA (average) |
| CURRENT DRAW IN HIBERNATION MODE | 2.23 mA (average) |
| POWER LOSS OPERATION | Finish recording event DVR records up to 10 seconds (if enabled) Powers the device long enough to save video and shut down properly in case of power loss due to tampering or collision. |
| DISCONNECT REPORTING | Yes |
| HIBERNATION | Default: 15 Min; Max: 60 hr |
| Installation | |
|---|---|
| ECM / ECU INTEGRATION | J1939 (250/500 kbps) and OBD-II |
| RECOMMENDED MOUNTING LOCATION | Windshield bulkhead |
| INSTALLATION SERVICES AVAILABLE | Lytx Professional Installation Services Training and support for client-managed installation |
| Included Accessories | |
|---|---|
| THE PURCHASE OF A DRIVECAM EVENT RECORDER INCLUDES: | • Cables for standard installation (power cable, vehicle interface cables) Diagnostic port (ECM) cables for light-duty and heavy-duty vehicles are available. • Mounting bracket with screws • Security retention clip • Informational guide |
